Grandstream GWN7605 Wireless Access Point, 802.11ac Wave-2 2x2:2 Wi-Fi Access Point

1 review(s) | Add your review

Features: The GWN7605 is an affordable 802.11ac Wave-2 Wi-Fi access point ideal for small to medium wireless network deployments with medium user density | It offers dual-band 2x2:2 MU-MIMO with beam-forming technology, supports up to 100+ concurrent client devices, and up to 165-meter coverage range.

₹ 8,828.00 excl tax

Manufacturer: Grandstream

SKU: GS-GWN-7605-WAP

Shipping

Delivery date 1 week

Download Technical Datasheet

Qty:

+ -

Overview
Reviews
Contact Us

| Description

The GWN7605 is an affordable 802.11ac Wave-2 Wi-Fi access point ideal for small to medium wireless network. deployments with medium user density. It offers dual-band 2x2:2 MU-MIMO with beam forming technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. To ensure easy installation and management, the GWN7605 uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface. The GWN7605 is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. It is the ideal Wi-Fi AP for voiceover-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi-capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 100+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the GWN7605 is a scalable Wi-Fi solution for deployments such as retail locations, restaurants, small offices and more.

1.27Gbps aggregate wireless throughput and 2xGigabit wireline ports.
Dual-band 2x2:2 MU-MIMO with beamforming technology.
Self power adaptation upon auto detection of PoE/PoE+.
Supports 100+ concurrent Wi-Fi client devices.
Up to 165-meter coverage range.
Advanced QoS to ensure real-time performance of low-latency applications .
Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device.
Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise-based software controller.

2x2mimo_web-01 device_screen_sharing

165_meters_web-01 qos_web web_configuration_icon

| Specifications

Wi-Fi Standards	IEEE 802.11a/b/g/n/ac (Wave-2)
Antennas	2 dual band internal antennas 2.4GHz, gain 3dBi 5 GHz, gain 3dBi
Wi-Fi Data Rates	IEEE 802.11ac: 6.5 Mbps to 867 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n: 6.5Mbps to 300Mbps; IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network.
Frequency Bands	2.4 GHz Radio: 2412 – 2484 MHz 5 GHz Radio: 5180-5825 MHz
Channel Bandwidth	2.4G: 20 and 40 MHz 5G: 20,40 and 80 MHz
Wi-Fi and System Security	WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES),anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
MIMO	2x2:2 2.4GHz (MIMO) 2x2:2 5GHz (MU-MIMO)
Coverage Range	Up to 165 meters *coverage range can vary based on environment
Maximum TX Power	2.4G:24dBm 5G:22dBm *Maximum power varies by country, frequency band and MCS rate
Receiver Sensitivity	2.4G 802.11b:-96dBm@1Mbps,-88dBm@11Mbps; 802.11g:-93dBm @6Mbps,-75dBm@54Mbps; 802.11n 20MHz:-73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7 5G 802.11a:-92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz:-67dBm@MCS8;802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
SSIDs	8 SSIDs per radio
Concurrent Clients	100+
Network Interfaces	2 x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports	1 x Reset Pinhole, 1 x Kensington lock
Mounting	Indoor wall or ceiling mount, kits included
LEDs	3 x tri-color LED for device tracking and status indication
Network Protocols	IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS	802.11e/WMM, VLAN, TOS
Network Management	Embedded controller can manage up to 50 local GWN APs GWN.Cloud offers a free cloud management platform for unlimited GWN APs GWN Manager offers premise-based software controller for up to 3,000 GWN APs
Power and Green Energy Efficiency	PoE 802.3af/ 802.3at; Maximum Power Consumption:10.16W
Environmental	Operation:0°C to 40°C Storage:-10°C to 60°C Humidity:10% to 90% Non-condensing
Physical	Unit Dimension:180.4mmx180.4mmx40.8mm; Unit Weight:388.2g Entire Package Dimension:228.5x220x79mm; Entire Package Weight:719.3g
Package Content	GWN7605 802.11ac Wireless AP, Mounting Kits,Quick Start Guide
Compliance	FCC, CE, RCM, IC
