| Wi-Fi Standards |
IEEE 802.11a/b/g/n/ac (Wave-2) |
| Antennas |
2 dual band external antennas
2.4GHz, gain 3.5dBi
5 GHz, gain 3.5dBi |
| Wi-Fi Data Rates |
5G:
IEEE 802.11ax: 7.3 Mbps to 1201 Mbps;
IEEE 802.11ac: 6.5 Mbps to 867 Mbps;
IEEE 802.11n: 6.5Mbps to 300Mbps;
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
2.4G:
IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps;
IEEE 802.11n: 6.5Mbps to 300Mbps;
IEEE 802.11b: 1, 2, 5.5, 11 Mbps;
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network. |
| Frequency Bands |
2.4GHz radio: 2412 - 2484 MHz
5GHz radio: 5180 - 5825 MHz
*Not all frequency bands can be used in all regions.
|
| Channel Bandwidth |
2.4G: 20 and 40 MHz
5G: 20,40 and 80 MHz |
| System Security |
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES),anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
| MIMO |
2×2:2 2.4GHz, 2×2:2 5GHz |
| Coverage Range |
Up to 250 meters
*coverage range can vary based on environment |
| Maximum TX Power |
2.4G:30dBm
5G:26dBm
*Maximum power varies by country, frequency band and MCS rate |
| Receiver Sensitivity |
2.4G
802.11b: -99dBm@1Mbps, -90dBm@11Mbps;
802.11g: -93dBm @6Mbps, -77dBm@54Mbps;
802.11n 20MHz: -74dBm @MCS7; 802.11n 40MHz:-72dBm @MCS7;
802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -62dBm @MCS11
5G
802.11a: -95dBm @6Mbps, -77dBm @54Mbps;
802.11ac 20MHz: -71dBm@MCS8; 802.11ac: HT40:- 67dBm @MCS9; 802.11ac 80MHz:-64dBm @ MCS9; 802.11ax 20MHz:-63dBm @ MCS11; 802.11ax
40MHz: -62dBm @MCS11;802.11ax 80MHz:-58dBm @MCS11 |
| SSIDs |
32 SSIDs total, 16 per radio (2.4GHz & 5GHz) |
| Concurrent Clients |
256+ |
| Network Interfaces |
2 x autosensing 10/100/1000 Base-T Ethernet Ports |
| Auxiliary Ports |
1x Reset Pinhole |
| Mounting |
Outdoor wall or pole mount, kits included |
| LEDs |
1× tri-color LEDs for device tracking and status indication |
| Network Protocols |
IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
| QoS |
802.11e/WMM, VLAN, TOS |
| Network Management |
Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN APs
GWN Manager offers premise-based software controller for up to 3,000 GWN APs |
| Power and Green Energy Efficiency |
PoE 802.3af/ 802.3at;
Maximum Power Consumption: 12.9W |
| Environmental |
Operation:-30°Cto 60°C
Storage: -30°C to 70°C
Humidity: 5% to 95% Non-condensing |
| Physical |
UnitDimension:358.3mm(L)x115mm(W)x45.3mm(H) Unit Weight:695g
Entire Package Dimension:275x185.5x89mm;
Entire Package Weight:995g |
| Package Content |
GWN7660LR 802.11ax Wireless AP, Mounting Kits, Quick Installation Guide |
| Weatherproof Grade |
IP66-level weatherproof capability when installed vertically |
| Compliance |
FCC, CE, RCM, IC |
