| Drive units (per speaker) |
Uni-Q Driver Array:
HF: 19 mm (0.75 in.) vented aluminium dome with Metamaterial Absorption Technology1
MF: 100 mm (4in.) aluminium cone
Uni-Core Force Cancelling Driver:
LF: 4 x 135 mm (5.25 in.) |
| Streaming services |
Spotify via Spotify Connect
Tidal via Tidal Connect
Amazon Music
Qobuz
Deezer
QQ Music via QPlay
Internet Radio
Podcasts
*Depends on services availability in different countries |
| Frequency range (-6dB) measured at 85dB/1m |
26 Hz - 36 kHz
*Depends on EQ settings |
| Frequency response (±3dB) measured at 85dB/1m |
31 Hz - 24 kHz
*Depends on EQ settings |
| Amplifier output power (per speaker) |
LF: 500W
MF: 100W
HF: 100W |
| Amplifier class (per speaker) |
LF: Class D
MF: Class D
HF: Class AB |
| Max SPL measured at 1m |
111 dB |
| Wireless streaming features |
AirPlay 2
Google Chromecast
Roon Ready
UPnP Compatible
Bluetooth 5.0
Plays with Audirvāna |
| Input resolution |
Network up to 24bit/384kHz
Optical up to 24bit/96kHz
Coaxial up to 24bit/192kHz
HDMI up to 24bit/192kHz
*Depends on source resolution |
| Interspeaker connection |
Wireless: all sources resampled to 24bit/96kHz PCM
Wired: all sources resampled to 24bit/192kHz PCM |
| Supported format (all inputs) |
FLAC, WAV, AIFF, ALAC, AAC, WMA, MP3, M4A, LPCM and Ogg Vorbis |
| Home Automation System |
Elan, RTi, Crestron Home, Savant, Control4 |
| Supported format (network) |
MQA, DSD |
| Wi-Fi network frequency band |
Dual-band 2.4 GHz / 5 GHz |
| Wi-Fi network standard |
IEEE 802.11a/b/g/n/ac
IPv4, IPv6
|
| Output |
Primary speaker
RCA Subwoofer output
Secondary speaker
RCA Subwoofer output |
| Inputs |
Primary speaker
HDMI eARC
TOSLINK Optical
Digital Coaxial
Analog RCA
USB Type A (service)
RJ45 Ethernet (network)
RJ45 Ethernet (interspeaker)
Secondary speaker
USB Type A (service)
RJ45 Ethernet (interspeaker) |
| Power input |
100 – 240VAC 50/60Hz |
| Power consumption |
450W (operating power)
<2.0W (standby power) |
| Dimensions (HWD per speaker) |
1090 x 212 x 394 mm (42.9 x 8.3 x 15.5 in.) with plinth
1042 x 130 x 321 mm (41.0 x 5.1 x 12.6 in.) without plinth |
| Weight (per set) |
|
